OV2710 CMOS Sensor 2MP HD Image Wide Angle USB2.0 Camera Module
Product Description:
ThisOV2710 CMOS Sensor 2MP HD Image Wide Angle USB2.0 Camera Modulebased on the OV2710-A68A (1/2.7 inch) sensor is equipped with a 120° diagonal ultra-wide angle lens, adopts a USB2.0 interface and fixed focus design, and is a standardized imaging component specially designed for scenarios such as wide-field acquisition and industrial monitoring. Its 1920×1080 (2MP) high resolution paired with a 6G+IR filter (650nm) can accurately restore details and effectively filter out stray light, with distortion controlled within 8% for clear and regular imaging; the 120° diagonal and 95° horizontal ultra-wide angle greatly expands single-frame coverage and reduces observation blind spots. The 30cm~∞ fixed focus requires no manual adjustment to ensure stable long-term operation; the USB2.0 interface integrates power supply and data transmission, plug-and-play to reduce integration difficulty. The PCB onboard stamp hole design (38×28×20mm) facilitates embedded installation, complying with RoHS and REACH dual compliance standards, and adapting to high-definition imaging needs in various scenarios.
Features:
１．120° Ultra-Wide Angle: 120° diagonal and 95° horizontal viewing angle, expanding single-frame coverage and reducing monitoring and detection blind spots.
２．2MP 1080P HD Output: 1920×1080 resolution with IR filter, ensuring excellent detail restoration and pure imaging.
３．USB2.0 Plug-and-Play: Integrated interface for power supply and data transmission, easy to operate and reducing integration difficulty.
４．Fixed Focus No Adjustment: 30cm~∞ focusing range, no manual operation required, ensuring stable long-term operation.
Technical Parameters:
| Module Size |
32mmx32mm |
| Pixel |
2MP |
| Sensor |
OV2710 |
| Resolution |
1920*1080 |
| Brand |
SincereFirst |
| FOV |
D120°*H95° |
| Output Format |
MJPEG |
| EFL |
2.56mm |
| Interface |
USB 2.0 High Speed |
Applications:
１．Wide-Angle Industrial Monitoring: Can be used for monitoring production lines, equipment and areas. With its ultra-wide angle and high-definition imaging, it can achieve large-scale high-definition video monitoring.
２．Embedded Vision Devices: Can be integrated into robots and self-service terminals. With its stamp hole design and easy integration, it can serve as a stable visual perception unit.
３．Close-Range HD Acquisition: Can be used for face recognition． With its high definition and fixed focus, it can complete accurate near-field acquisition.
４．Automotive/Security Wide-Angle Imaging: Can be used in automotive and security scenarios. With its wide field of view, it can improve environmental perception and security monitoring capabilities.
Customized Service:
We can customize module shape, module head size, lens holder, imaging direction, VCM, lens, firmware, etc.
Why Choose us?
Customized Process:
1. You can provide drawings or samples, as well as request documentation and developed by
our engineering staff.
2. Communication or Meeting
3. We will communicate with you in detail to determine somewhat product you need and try to set the most suitable product for you
according to your needs.
4. Sample Development
5. Determine the details of the development sample and the delivery time. Communicate at any time to ensure smooth progress.
6. Sample Testing
7. Test and age on your application, feedback test results, no need to modify, mass production.
